Technical highlights
● fast control algorithms
○ current control: min. 62.5 μs
○ speed control: min. 62.5 μs
○ position control: min. 62.5 μs
● variably adjustable current and speed filters
● high-speed EtherCAT system communication
● 1- or 2-channel Servo Drive
○ optimised for multi-axis applications
○ variable motor output current in 2-channel drives
● active DC-Link and brake energy management via AX-Bridge
● variable motor interface with
○ multi-feedback interface
○ flexible motor type selection
○ scalable, wide range motor current measurement
○ OCT (One Cable Technology)electronic identification plate
● high-speed capture inputs
○ eight programmable digital I/Os, two with timestamp
● mains connection
○ wide voltage range 100…480 V AC
○ integrated mains filter
● integration of safety functions (optional)
○ STO, SS1
○ TwinSAFE: intelligent safety functions for Motion Control with AX58xx
● compact design for simple control cabinet installation (300 mm depth)
● AX-Bridge – the quick connection system for power supply, DC-Link and control voltage
● variable cooling concept (fanless, forced cooling)
